Miniature Aluminum Electrolytic Capacitors（点击"Type ･ Series"或"Page"可打开相应的PDF文件） Classification Type
･ SeriesConfiguration Applications Category
Temperature
Range (°C)Features Rated
Voltage
Range
(V.D.C)Rated
Capacitance
Range
(μF)Tolerance on
Rated
Capacitance
(%)Page Standard type Smaller-sized &
low profileLow impedance Long life Anti-cleaning solvent Ultra-Miniature
typeUMA 04 5mmL, Standard,
For General
Purposes–40 to +85 ● ● 4 to 50 0.1 to 470 ±20 164 UMP 04 5mmL, Bi-Polarized –40 to +85 ● ● 6.3 to 50 0.1 to 47 ±20 165 UMT 04 5mmL,
Wide Temperature
Range–55 to +105 ● ● 4 to 50 0.1 to 100 ±20 166 UMF 04 5mmL,
Low Impedance–55 to +105 ● ● 6.3 to 35 1 to 100 ±20 167 UMV 04 5mmL,
Long Life Assurance–40 to +105 ● 4 to 50 0.1 to 100 ±20 168 USA 04 7mmL,
For General Purposes–40 to +85 ● ● 6.3 to 50 0.1 to 220 ±20 169 USR 04 7mmL High C / V –40 to +85 ● ● 4 to 50 0.1 to 470 ±20 169 USP 04 7mmL,
Bi-Polarized–40 to +85 ● ● 6.3 to 50 0.1 to 220 ±20 170 UST 04 7mmL,
Wide Temperature
Range–55 to +105 ● ● 6.3 to 50 0.1 to 220 ±20 171 USV 04 7mmL,
Long Life Assurance–40 to +105 ● 6.3 to 50 0.1 to 220 ±20 172 USF 04 7mmL,
Low Impedance–55 to +105 ● ● 6.3 to 35 6.8 to 220 ±20 173 Standard
typeUVK 04 Miniature Sized,
Standard–40（–25）
to +85● ▲ 6.3 to 450 0.1 to 68000 ±20 174 UVR 04 Standard –40（–25）
to +85● ▲ 6.3 to 450 0.1 to 33000 ±20 176 UVC 04 High Voltage,
Ultra-Miniature Sized,
For Adapters–40 to +105 ● 400 4.7 to 18 ±20 190 TVX 02 Standard, For General
Purposes–40 (–25)
to +85● ▲ 6.3 to 450 0.47 to 10000 ±20 178 UVY 04 Miniature Sized,
Wide Temperature
Range–55（–40,
–25）
to +105● ▲ 6.3 to 450 0.1 to 68000 ±20 180 UVZ 04 Wide Temperature
Range–55（–40,
–25）
to +105● ▲ 6.3 to 450 0.1 to 33000 ±20 182 URS 04 Compact & Standard
For General Purposes–40 to +85 ● ▲ 6.3 to 400 0.1 to 10000 ±20 184 URZ 04 Low-Profile Sized,
Wide Temperature
Range–55（–40）
to +105● ▲ 6.3 to 400 0.1 to 10000 ±20 186 URY 04 12.5mmL Wide
Temperature Range–55（–40,
–25）
to +105● ▲ 6.3 to 450 6.8 to 4700 ±20 188 UVP 04 Bi-Polarized –40 to +85 ● ● 6.3 to 100 0.47 to 6800 ±20 191 UEP 04 Bi-Polarized,
Wide Temperature
Range–55 to +105 ● ● 6.3 to 100 0.47 to 6800 ±20 193 High Reliability type UPM 04 Low Impedance,
High Reliability–55（–40,
–25）
to +105● ● ▲ 6.3 to 450 0.47 to 15000 ±20 194 UPW 04 Miniature Sized,
Low Impedance,
High Reliability–55（–40,
–25）
to +105● ● ● ▲ 6.3 to 450 0.47 to 15000 ±20 201 UTT 04 Miniature Sized,
Low Impedance,
High Reliability–40 to +105 ● ● ● ● 6.3 to 50 1 to 470 ±20 206 UPA 04 Miniature Sized,
Low Impedance,
High Reliability–55 to +105 ● ● ● ● 6.3 to 35 180 to 10000 ±20 208 UHV 04 Extremely
Low Impedance,
High Reliability–40 to +105 ● ● ● ● 6.3 to 35 47 to 8200 ±20 210 UHD 04 Extremely
Low Impedance,
High Reliability–40 to +105 ● ● ● 6.3 to 50 22 to 6800 ±20 212 UHE 04 Extremely
Low Impedance,
High Reliability–40 to +105 ● ● ● ● 6.3 to 100 0.47 to 18000 ±20 215 UHW 04 Extremely
Low Impedance,
High Reliability–40 to +105 ● ● ● ● 6.3 to 50 220 to 15000 ±20 220 UPJ 04 Low Impedance,
For Switching
Power Supplies–55（–40,
–25）
to +105● ● ● ▲ 6.3 to 450 0.47 to 15000 ±20 223 UPS 04 Miniature Sized,
Low Impedance,
For Switching
Power Supplies–55（–40,
–25）
to +105● ● ▲ 6.3 to 450 0.47 to 15000 ±20 230 UPV 04 Miniature Sized,
Low Impedance,
High Reliability–55 to +105 ● ● ● 6.3 to 50 0.47 to 390 ±20 232 UPT 04 Miniature Sized,
High Ripple Current,
Long Life–25 to +105 ● ● 200 to 450 15 to 820 ±20 234 UPZ 04 High voltage,
MiniatureSized–25 to +105 ● 200 to 450 18 to 470 ±20 236 UPH 04 High voltage,
MiniatureSized–25 to +105 ● 400 to 450 27 to 220 ±20 238 UCP 04 High voltage,
MiniatureSized,
Long Life Assurance–25 to +105 ● ● 400 to 450 27 to 220 ±20 239 ULD 04 Miniature Sized,
Long Life Assurance–40（–25）
to +105● 10 to 450 1 to 330 ±20 240 UCA 04 Miniature Sized,
High Ripple Current,
Long Life–25 to +105 ● ● 160 to 450 6.8 to 220 ±20 242 UCS 04 Miniature Sized,
High Ripple Current,
High Reliability–40（–25）
to +105● ● 160 to 450 6.8 to 330 ±20 244 UCY 04 Miniature Sized,
High Ripple Current,
High Reliability–40（–25）
to +105● ● 160 to 500 6.8 to 680 ±20 246 UPX 04 Long Life Assurance,
High Reliability–55 to +105 ● ● ● 10 to 35 1 to 4700 ±20 248 UBT 04 High Temperature Range,
For Industrial equipment
(125°C)–40（–25）
to +125● ▲ 10 to 450 1 to 4700 ±20 250 UBW 04 High Temperature Range,
For Industrial equipment
(135°C)–55 to +135 ● ● 10 to 100 1 to 4700 ±20 252 UBX 04 High Temperature Range,
For Automobile equipment
(150°C)–55（–40,
–25）
to +150● ▲ 10 to 400 1 to 4700 ±20 254 TBE 02 High Temperature Range,
For Industrial equipment
(125°C)–40 to +125 10 to 50 0.47 to 470 ±20 256 Special
equipmentUKL 04 Low Leakage Current –40 to +85 ● ● 6.3 to 100 0.1 to 10000 ±20，±10 257 UAQ 04 For Permissible
Abnormal Voltage–40 to +105 200, 400 10 to 220 ±20 259 UAS 04 Miniature sized,
For Permissible
Abnormal Voltage–40 to +105 ● 200, 400 4.7 to 330 ±20 260 For
audio equipmentUKA 04 105°C For High Grade
Equipment–55 to +105 ● 6.3 to 50 22 to 22000 ±20 261 UKZ 04 Premium Grade Type,
For Audio Equipment–40 to +85 ● 25 to 100 10 to 1000 ±20 262 UFG 04 High Grade Type,
For Audio Equipment–40 to +85 ● ● 6.3 to 100 0.1 to 10000 ±20 263 UKT 04 105°C Standard,
For Audio Equipment–55 to +105 ● ● 6.3 to 50 0.1 to 33000 ±20 265 UKW 04 Standard,
For Audio Equipment–40 to +85 ● ● 6.3 to 100 0.1 to 33000 ±20 266 UFW 04 Standard,
For Audio Equipment–40 to +85 ● ● 6.3 to 100 0.1 to 33000 ±20 267 USW 04 7mmL,
For Audio Equipment–40 to +85 ● ● 6.3 to 50 0.1 to 220 ±20 269 UMW 04 5mmL,
For General
Audio Equipment–40 to +85 ● ● 4 to 50 0.1 to 470 ±20 270 UUQ 32 105°C Chip Type,
For Audio Equipment–40 to +105 ● 6.3 to 50 0.1 to 1000 ±20 271 UES 04 Bi-Polarized,
For Audio Equipment–40 to +85 ● ● 6.3 to 50 0.47 to 1000 ±20 273 UDB 04 Bi-Polarized,
For Speaker Network–40 to +85 ● ● 50 1 to 68 ±20 274 Above description is a feature against AK-225AES.
▲ : Applicable up to 100V ratings or less.CAT.8100E
